2009 FINISHING SYSTEM 20'L X

2009 FINISHING SYSTEM 20'L X 12'W X8'H STEAM HEAT TURBULATOR OVEN [FO-010289] in United States

Location:
United States
Manufacturer:
FINISHING SYSTEM
Model:
20'L X 12'W X8'H

Specifications

Condition:
used
Year:
2009
Recnum:
FO-010289
Comments:
A lot of machine & equipment value for the money!
Machtype:
STEAM HEAT TURBULATOR OVEN
Condition info:
(8-9) Reconditioned [9]
Current status:
Active
Elect./voltage:
600 V, 60 Cy, 3 Ph.
Appr. repl. cost:
237500

Description

Oven Dimensions (overall): 12' Wide x 20' long x 9' high.

-- Utilities - Electrical: 480 Volt, 3-Phase, 60 Hz; Heating Source: Steam.

-- (2) Steam Coils (2) rows 20" x 96".

-- Oven enclosure consists of: 4" Thick x 12' long x 27" wide Heavy tongue & groove panels. The floor of your plant will be the floor of the oven so that you can roll carts in and out with any problems.

-- Two (2) 7' high x 6' wide doors that will make a 7' high x 12' wide opening at one end of the oven and for $1,100.00 one set of doors at each end of the oven

-- Two (2) Overhead turbulator type fans, 3 HP. ea. at 20,000 CFM each; (1) access oven man doors.

-- (1) 12" diameter, 0.75 HP motoer @ 1,000 CFM exhaust fan with open drip-proof motor and control.

-- Control Panel will be pre-wired shop tested; free-standing NEMA-12 control panel will be furnished with circuits prewired to terminal strips; includes (3) motor starters, temperature controller, (1) door-mounted disconnect with interlock hardware to prevent opening the door without disruption the poweer supply.

-- (1) Control voltage transformer will be furnished to reduce the voltage to 110 volts for the oven control circuits.

-- Modulating "heat & temperature": Indicating controller for temperature, operates a controller valve.

-- DESIGNED FOR YOUR NEEDS FOR MANY YEARS OF PRODUCTION!!
