2007 SCHELLING FH6-430 REAR LOAD,

2007 SCHELLING FH6-430 REAR LOAD, AUTOMATIC PANEL SAW [PH-012069] in Italy

Location:
Italy
Manufacturer:
Schelling
Model:
FH6-430

Specifications

Condition:
used
Year:
2007
Recnum:
PH-012069
Comments:
An exceptionally well-maintained machine & READY for IMMEDIATE DELIVERY!
Machtype:
REAR LOAD, AUTOMATIC PANEL SAW
Condition info:
(7-9) Excellent condition [7]
Current status:
Active
Elect./voltage:
400 V, 50/60 Cy, 3 Ph.
Appr. repl. cost:
248000

Description

SCHELLING FH6-430 Rear Load, Automatic Panel Saw:

-- Specifications:169" (4,300 mm) Rip Cutting cap.; 5.3" (135 mm) saw blade projection; 37 HP (27 kW) - 3.800 RPM main motor, 3 HP (2.2 kW) - 5,500 RPM scoring motor.

-- Saw Carriage:Variable saw carriage travel speed from 20 - 492 FPM (6 - 150 MPM), constant return of 492 FPM (150 MPM).

-- Pusher Fence:Programmable overhead program fence, rack & pinion driven on both sides; forward speed from 0.3 - 262 FPM (1 - 80 MPM), forward speed is currently set at 0 - 82 FPM (0 - 25 MPM) for CE standards and can be changed, constant return speed of 262 FPM (80 MPM);Pusher fence with (8) material gripper clamps, clamps open to 4.9" (125 mm).Automatic feeding with DOUBLE rear pushing system, the 1st pusher moves the panels from the lift table while the 2nd pusher with gripper clamps moves the panels toward the cut-line for processing at the same time; (3) electro-pneumatic aligning devices for feeding from lift table.

-- Operator & Machine Control:PC Front-end controller with: SCHELLING "MCS Evolution" 2.0 + "Windows" operating systems; TFT 17" screen displays cutting dimensions & patterns w/moving graphics, self-diagnostic, data input by keyboard or direct downloading from office PC is possible.

-- Lift Table:4-Post electronically controlled screw type panel stack lift table, 9,900 Lbs (4.500 KG) cap.; max. bunk height 27.5" (700 mm) without a pit or risers, 32" (813 mm) max. bunk height with 7" (178 mm) pit;

-- Complete with:90.5" (2,300 mm) Long crosscut fence (front-to-back), (2) side/crosscut aligners, (1) in front & (1) back of the cut-line, up to 87" (2,210 mm) crosscutting cap.(1) SCHELLING Powered rotating 0° - 90° solid front support table with air flotation for moving panel from rip position to cross-cut position, 165.3" x 86.6" (4,200 x 2,200 mmFully enclosed for safety with man-height sheet metal panels & wire screen windows.

-- Options Include: Rear load in-feed system with fork cut-outs, 169.2 (4,300 mm)" x 87" (2,200 mm), Actual model is SCHELLING "FH6 430/430".Note: EX-FACTORY’s Logistic Department is experienced and setup to provide “Full Service Logistic� from Overseas Suppliers to your Door. …Packaging, Container Loading, Ocean Freight, Marine Insurance (door to door), US or Canadian Customs, Duty and domestic shipping to your Plant Door.
