2003 FALCIONI/CEFLA RE-2400-14 CARRSEL OVEN

2003 FALCIONI/CEFLA RE-2400-14 CARRSEL OVEN HOT AIR OVEN BY HOT WATER [FO-010294] in United States

Location:
United States
Price:
$35,100 USD
Manufacturer:
Cefla
Model:
RE-2400-14 CARRSEL OVEN

Specifications

Condition:
used
Year:
2003
Recnum:
FO-010294
Comments:
A machine in this condition and specification is hard to find!
Machtype:
HOT AIR OVEN BY HOT WATER
Condition info:
(7-9) Excellent condition [8]
Current status:
Active
Elect./voltage:
480 V, 60 Cy, 3 Ph.
Appr. repl. cost:
75500

Description

This FALCIONI / CEFLA is a great way to cure finished wood product of all sizes and shapes. Casegoods, flat panels, assembled furnituer up to 51" Width cap.

-- There are 12 carts that are 3' x 7' that are attached to a drag chane conveyor by one side of the cart. The carts are loaded with wet painted parts and then pulled thru a system with a heated forced air flow in the direction to allow for a gentle & fast evaporation of different solvents or water based coatings.

-- Adjustable & controllable air-flow recycle system makes this the most advanced & energy efficient flash-off oven in the industry today.

-- The ventilation system includes an air inlet & recirculation unit with supplied heat exchanger of a hot water boiler & seperate exaust ventilation; the air volume is controlled by adjustable dampers; Electro-mechanical 3-way valve automatically controls air tempurature adjustment; Fresh air to the oven is combined with recycled air providing a siginificant amount of energy savings; Air inlet & exaust are designed to ensure constant air speed thoughout the entire oven section.

-- The frame structure is enclosed by sandwich panels made of steel & polyurethane insulated foam to increase the trermal efficiency;

-- Actual specifications of this system: Temperature -Max 170°F, Incloesed oven area is 83' long with 31' of flash and 52' of full temperature, The conveyor leight of travel is 164',

-- Electrical: 480V 3Hp 60 Hz total 52 amp.,

-- BOILER: AMTROL INC. model AX 20V Propain Gas out door unit.
