2016 TURBO BURN TB-3 HOT
Location:
United States
Price:
$15,055 USD
Manufacturer:
TURBO BURN
Model:
TB-3

Specifications

Condition:
new
Year:
2016
Recnum:
BD-010196
Comments:
Finally, a heat source plus heat storage at an affordable price!
Machtype:
HOT WATER NON-BOILER FURNACE
Condition info:
Brand New w/Warranty
Current status:
Brand New
Elect./voltage:
220 V, 60 Cy, 1 Ph AND 3 Ph.
Appr. repl. cost:
15055

Description

The TURBO BURN TB series of stored energy systems are oversized open to the atmosphere hot water vessels that range in size from the TB-1 with a rating of 750,000 BTU's/Hr. and a stored energy capacity of 1,900,000+. BTU's: to the TB-6 with a rating of 3,100,000 BTU's/Hr and a stored energy capacity of 8,500,000+ BTU's. These non- pressurized non-boilers will burn bio-mass, wood scrap of all types, coal, crop wastes, card board, etc. A true multi-fueled appliance each unit is also capable of burning liquid hydrocarbons oil, used oil, vegetable oil, diesel etc. and also propane, gas and even electricity and solar dependant on what's available to the customer for fuel. These units are induced draft furnaces using air to increase combustion temperatures in excess of 2500 degrees when burning bio-mass for a complete and total burn. Energy not consumed by demand is stored by design in the water encapsulated in this well insulated appliance for later use. Extremely simple technology with each unit custom built to supply heat and if necessary thousands of gallons of hot water per hour to satisfy all the needs of the end user. __ The TB-3 is a hot water non boiler-furnace designed with a ideal internal water temperature target of 200F. __ Burning time: 2-3 hours__ On Demand 1,200,000 BTU's/Hr. Stored energy capacity at 200 degrees F 3,482,173 BTU's.__ Water holding capacity: 1280 Gallons of water. (more flue tubes for faster heat recovery) __ Max. Sq. Ft. 30,000.__ Unit size 3'Wide x 6'High x 7'Length __ Firebox dimensions: 36 Deep x 24" High x 24" Wide and door dimensions of 14" x 20", weight 2350 Lbs empty.__ Internal 60' copper heat exchanger for potable hot water( can add up to 4 more internal heat exchangers to this model)__ Internal relief vent, clear sight tube, water temp gauge, removable lid, flue brush, TB811 chemical treatment, cleanout port, 4x4 skids__ See other listings for additional models of this equipment.
