- Teledyne Readco 10" Co-Rotating Twin Screw Continuous Processor. 72" long barrel of 304 stainless steel wetted parts, 17-4PH hardened shafts and 125RA or better finish in Bensenville, IL

Location:
Bensenville, IL
Manufacturer:
Teledyne

Specifications

Condition:
used
Stock number:
44592008
Hp:
300
Dia (in):
10
Category:
Mixers
Subcategory:
Continuous mixers

Description

44592008 Used- Teledyne Readco 10" Co-Rotating Twin Screw Continuous Processor. 72" long barrel of 304 stainless steel wetted parts, 17-4PH hardened shafts and 125RA or better finish. Two zone jacketed clamshell barrels, rated for 150 psig at 500 deg F, with discharge shroud chute, infrared temperature sensor, electrically actuated slide gate, terminal junction box, injection ports. Nuthall helical parallel gear reducer. Torque rating of 176,000 in/lb with 7.741:1 reduction ratio, with a mechanical horsepower rating of 632 hp, with low and high temperature switch. Reliance 300 hp TEFC, 460 volt, 3 phase, 1800 rpm motor. Unit built 1996.
