Location:
Bensenville, IL
Model:
Y3

Specifications

Condition:
used
Serial number:
Y30109
Stock number:
44747005
Hp:
3
Subcategory:
Mixers
Subcategory 2:
Homogenizer mixers

Description

44747005 Used- Quadro Y-Tron Y Jet High Speed Disperser, Model Y3, Stainless Steel. Liquid blending/solid suspension batch size 6000 gallon, powder incorporation batch size 1000 gallon, powder feed rate 150 pounds per minute. Driven by a 3hp, 3/60/208-230/460 volt, 1770 rpm motor, serial# Y3-0109, built 1998. Includes an approximate 200 gallon 304 stainless steel tank, 32" diameter x 60" straight side, flat top with 1/2 hinged cover, dished bottom. Side openings 6" drive, 3". 2" Center bottom outlet. Mounted on 3 stainless steel legs.
