Location:
Bensenville, IL
Manufacturer:
S Howes

Specifications

Condition:
used
Stock number:
46075090
Hp:
3
Cubft:
1700
Material:
304 SS
Subcategory:
Mixers
Subcategory 2:
Ribbon blenders

Description

46075090 Used- S. Howes Ribbon Blender, Approximate 1700 Total Cubic Feet, 304 Stainless Steel. Enclosed horizontal tank approximate 120" diameter x 240" straight side, dished ends, internal rated 15 psi at 100 degrees F. Internal shaft with approximate 14" diameter shaft, welded on 3" diameter posts, inner ribbon approximately 2-1/2" wide x 5/8" thick, outer ribbon approximately 2" wide x 5/8" thick, driven by a 3 hp, 3/60/230/460 volt, 1730 rpm XP motor with Falk reducer, ratio 512.4 to 1, approximate 1.6 final rpm. Top openings: (1) 24" manway with cover, (3) 8", (1) 4", (2) 3", bottom outlets. National Board# 1, Serial# 114720, Built 1981. Currently mounted on concrete saddles, end frame mounting.
