- Imperial Industries Silo, 3,074 Cubic Feet (22,995 Gallon), Model 60-35 12-0Y49-0, Carbon Steel, Vertical in Bensenville, IL

Location:
Bensenville, IL
Manufacturer:
MAN
Model:
60-35 12-0Y49-0

Specifications

Condition:
used
Serial number:
T31415
Stock number:
45134006
Cubft:
3074
Bottom:
Coned Bottom
Gallons:
22,995
Dia (in):
144
Diameter:
144"
Material:
CS
Height(in):
588
Inlet size:
20" man way with cover, 10", 4", 43" x 43"
Year built:
2002
Straight side:
306-1/4"
Working capacity:
3,074 Cubic feet
Overal dimensions:
622"L X 145"W X 145"T
Material of construction:
Carbon Steel
Category:
Silos

Description

45134006 Used- Imperial Industries Silo, 3,074 Cubic Feet (22,995 Gallon), Model 60-35 12-0Y49-0, Carbon Steel, Vertical. 144" Diameter x 256-1/4" straight side. Slight coned top, 55-3/4" 60 degree coned bottom. Height from ground to top tangent line 49. Designed for Seismic zone 1, maximum wind load 90 miles per hour, maximum material density 35 pounds a cubic foot, maximum internal pressure 0.38 psi, maximum internal vacuum 0.03 psi, maximum tonnage 53,795. Includes bottom skirt mounting with double door, Metalfab bin activator with 12" outlet with a rotary valve, Ramsey belt weigher with controller, top mounted MAC bin vent dust collector, (2) section side ladder, and top safety rail. Serial# T-31415, built 2002.
