Location:
Bensenville, IL
Manufacturer:
MAN tanks
Size:
2"

Specifications

Condition:
used
Serial number:
97/G09166
Stock number:
46075151
Bottom:
Dished Bottom
Gallons:
500
Opening:
Top: 18" man way with hinged cover, (1) 4" for agitator, (3) 2".
Diameter:
48"
Mixer type:
Dual 3 Blade Turbine
Agitator hp:
1/3
Outlet size:
2"
Agitator rpm:
1725
Agitator type:
Top Entering
Straight side:
60"
Agitator cycle:
60
Agitator model:
XJCA-33
Agitator phase:
3
Top head style:
Dished Head
Outlet location:
Bottom
Agitator voltage:
208-230/460 Volt
Agitator location:
Top Offset
Overal dimensions:
93"L x 60"W x 54"T
Agitator manufacturer:
Lightnin
Horizontal or vertical:
Vertical
Material of construction:
304 Stainless Steel
Subcategory:
500 to 999 gallons
Subcategory 2:
Stainless steel tanks

Description

46075151 Used- Tank, 500 Gallon, 304 Stainless Steel, Vertical. Approximate 48" diameter x 60" straight side, dished top and bottom. Off center top entering Lightnin agitator, model XJCA-33, serial# 97/G09166. Approximate 1-1/4" diameter shaft and dual 3 blade turbine, driven by a 1/3 hp, 3/60/230/460, 1725 rpm, XP motor with mechanical seal. Openings Top: 18" man way with hinged cover, (1) 4" for agitator, (3) 2". 2" Center bottom outlet. Provision for 4 legs.
