Top Seller
50" x 12", WILLIS, 7.5
Location:
Hialeah, FL
Manufacturer:
Willis

Specifications

Condition:
used
Stock number:
4484
Division:
Metalworking
Inbound freight from toledo, oh:
950.00
Subcategory:
Drills, radial
Subcategory 2:
Drilling & tapping

Description

Inbound freight from Toledo, OH . . . . . . . . . . . . . . . . 950.00
STANDARD ACCESSORIES:
7.5 HP, 220/440 volt, 3 phase, 60 Hz motor with switch and wiring complete
Power arm elevation, Hydraulic clamping, Box work table
Flood coolant system, Work light
Tool box with necessary wrenches and spanners
Instruction manual and parts list
SPECIFICATIONS:
Column diameter 12" (300mm)
Distance from spindle
center to column--maximum 51" (1300mm)
nose to base--maximum 48" (1200mm)
Horizontal travel--spindle head 34" (8500mm)
Spindle speeds--number 12
--range 44 to 1500 rpm
Spindle taper #5MT
Quill travel 10" (25038mm)
Quill powerfeed--number 3
--range .002/.0036/.006"
Drilling--mild steel 2-1/8" (53mm)
Motors--main spindle 7.5 HP
--arm elevating 2 HP
--coolant pump 1/8 HP
Power-electrical 60 Hz., 3 ph. 220/440 Volt
Dimensions (L x W x H) 32" x 72" x 87"
(800mm x 1800mm x 2175mm)
Machine net weight/Shipping 6300
