Top Seller
2'4" x 8 1/4", WILLIS,
Location:
Hialeah, FL
Manufacturer:
Willis

Specifications

Condition:
used
Stock number:
4328
Delivery:
Stock Ohio
Division:
Metalworking
Export crating:
750.00
Inbound freight from los toledo, oh:
750.00
Subcategory:
Drills, radial
Subcategory 2:
Drilling & tapping

Description

Inbound freight from Los Toledo, OH . . . . . . . . . . . . . . . . 750.00
Export crating. . . . . . . . . . . . . . . . . . . . . . . . . . . 750.00
STANDARD ACCESSORIES:
2 HP, 220/440 volt, 3 phase, 60 Hz motor with switch and wiring complete
Power arm elevation
Box work table
Coolant system
Work light
Tool box with necessary wrenches and spanners
Instruction manual and parts list
SPECIFICATIONS:
Column diameter 8 " (212.55mm)
Distance from spindle
center to column--minimum 8-7/16" (212mm)
--maximum 30" (757mm)
nose to base--minimum 11-1/8" (283mm)
--maximum 43 3/4" (1104mm)
Horizontal travel--spindle head 21-1/4" (540mm)
Vertical travel of arm 21-5/8" (550mm)
Spindle speeds--number 6
--range 88 to 1500 rpm
Spindle taper #4MT
Quill travel 8" (200mm)
Quill powerfeed--number 3
--range .002/.0035/.006"
Drilling--cast iron 2"
--mild steel 1-1/2"
Boring--cast iron 4"
--mild steel 3"
Tapping--cast iron 1"
--mild steel 3/4"
Work table dimension (L x W x H) 19 3/4" x 16" x 13 7/8"
Work area of base 24-13/16" x 34"
Base floor space 50" x 25" (1260 x 640)
Motors--main spindle 2 HP
--arm elevating 1 HP
--coolant pump 1/8 HP
Power-electrical 60 Hz., 3 ph. 220/440 Volt
Machine net weight/Shipping 2420 lbs/2970. (1100 KG)
DELIVERY: Stock Ohio
