GMC GML-1640HD, Engine Lathe, 6
Location:
Hialeah, FL
Manufacturer:
GMC lathes

Specifications

Condition:
used
Stock number:
6271
Motor:
6 HP 220/440 volts / 3 phase, Micrometer carriage stop
Division:
Metalworking
Inland freight to miami, fl:
950.00
60" center lathe instead of 40:
1,000.00
Subcategory:
Lathes, engine

Description

OPTIONAL ACCESSORIES:
SINO digital readout system, installed . . . . . . . . . . . . . . $ 1,000.00
60" center lathe instead of 40". . . . . . . . . . . . . . . . . . 1,000.00
Inland freight to Miami, FL. . . . . . . . . . . . . . . . . . . . 950.00
STANDARD ACCESSORIES:
Removable gap
Motor:6 HP 220/440 volts / 3 phase, Micrometer carriage stop
8" 3 dia. jaw chuck with D1-6 direct mount
10" 4 dia. jaw chuck with D1-6 direct mount
12" Face plate, Splash guard, Steady rest, Follow rest
Centers and sleeve, Tool box, Four sided toolpost, Coolant system
Work light, Thread chasing dial, Taper attachment
Inch/metric threading, Dual inch/metric dials
Misc. wrenches and tools, Operation & parts manual
Full length foot brake, Full length splash guard
FEATURES:
ISO 9001 certified
One-piece cast iron base, No change gears required
Main spindle hardened & precision ground
Bed made of fine grain high tensile cast iron
Bedways induction hardened & precision ground
All gears and shafts hardened & precision ground
Main spindle supported at 3 point by precision bearings
SPECIFICATIONS:
Swing over bed 16"
Swing over cross slide 10-1/4"
Swing over gap 23-1/4"
Length of gap 8-1/2"
Distance between centers 40"
Width of bed 10"
Hole thru spindle 2-1/16"
Spindle nose D1-6
Spindle speeds--number 16
--range 45 to 1800
Inch threads--number 45
--range 2 to 72 tpi
Metric threads--number 39
--range .2 to 14 mm
Tailstock spindle travel 4-3/4"
Tailstock taper #4 MT
Motor HP 6 HP
Coolant pump motor 1/8 HP
Electrics 220/440/3ph/60Hz
Net weight 4,150 lbs
Dimensions (L x W x H) 79" x 38" x 56"
