For Non-Ferrous materials; Aluminum, Brass, Copper,
and PVC, ect, Fully hydraulic and automatic operation: auto feeding.
clamping and cutting. It is well equipped with 2 AC Motors;
Main saw head motor 15 HP. 3 PH 220/440 volts 1740 RPM and 3 HP.
3 Ph 220/440 volts for hydraulic pump.
Blade diameter, carbide tip blade 20" to 24"
Cut capacity W 7.25" X H 6.75"
With multiple feeding strokes single stroke is 14"
Cutting speed infinitely variable
Cutting squareness; vertical .0007", horizontal .003 in per/ft
and repeat .005" per 1" stroke
Feeding rate; 42.3"/min., with vertical & horizontal clamping
system for single and bundle cutting.
Control pannel is well design for user's friendly and with
touch sensor screen.
Solid state PLC with CNC control system will enhance trouble
free reliable operation.
Safety devices and emergency stop are well provided in many
locations including saw blade cover.
Chip collecting system model SDC-2024, is provided, Carbide 20"
blade x any teeth, Standard tools and operations manual.
22" - 24" blades. . . . . . . . . . . . . . . . . . . . . . . call for quote
Unist mist applicator modefied and installed. . . . . . . . . $ 750.00
Machine is FOB Vernon, CA. Delivery 7-8 weeks after receipt of approved
credit and down payment. Above equipment carries a 1 year warranty
parts and labor, except for chip collector which carries 60 days.
Factory to provide machine start up and training. In the event the
technician is required for any services during the warranty period,
Buyer is fully responsible for travel expenses only.
