Top Seller
5/16" x 10', ACCU-MAQ, #10-312,
Location:
Hialeah, FL
Manufacturer:
Accumaq

Specifications

Condition:
used
Stock number:
5851
Division:
Metalworking
Inland freight to hialeah, fl:
1,500.00

Description

OPTIONS:
ESTUM model E20 programmable back guage, factory installed. . . . . $ 5,000.00
Inland freight to Hialeah, Fl . . . . . . . . . . . . . . . . . . . 1,500.00
SPECIFICATIONS:
Maximum cutting length 126" (3200mm)
Maximum shearing capacity, mild steel 5/16" (8mm)
Throat depth 5.7" (145mm)
Number of strokes per minute 10
Backguage length 34" (850mm)
Blade rake 1 degree 30 minutes
Main motor power 15 HP (11 KW)
Dimensions (L x W x H) 151" x 73" x 68"
(3850mm x 1830mm x 1720mm)
Net weight 16,080 lbs (7700 kg)
STANDARD FEATURES & ACCESSORIES:
Front operated power back gauge with 34" travel and elctronic
digital readout with fine adjustment
Foot pedal with emergency stop
Squaring arm, Front arm supports
Hydraulic pump and valves manufactured by Rexroth (Bosch)
Seals manufactured by Valqua (Japan) and Fietz (Germany)
Most electrical parts are manufactured by Schneider and/or Omron
Nitrogen filled counter balance accumulators
Gap adjustment with digital indicator, Shadow light
Single or continuous operation, Cycle counter
