Location:
United States
Price:
No price
Manufacturer:
ATC machining centers
Model:
M14 HORIZONTAL MACHINING CENTER
Spindle Taper:
CAT #50

Specifications

Condition:
used
Year:
1997
Stock number:
31126
B-axis:
360,000 Full Contouring
Rapid travel:
400 IPM
Spindle speed:
20 - 3000 RPM
Spindle taper:
CAT #50
X-axis travel:
110"
Y-axis travel:
78.7"
Z-axis travel:
59"
(3) pallet size:
49" x 40"
Tool changer capacity:
200 ATC

Description

Equipped With
Mandelli Plasma CNC
Renishaw Probing
Universal Spindle for Horizontal or Vertical Milling
High Pressure Coolant
Chip Conveyor/Filter
53.6 HP Main Drive Motor
39.97 kw Main Drive Motor
Full Enclosure
3 Pallet Changers
Dimensions and Weight
420"x 300"x 144"
10668mm x 7620mm x 3658mm
125000
56688 Kg
