No. DV-59, Hardinge, 9" swing,
Location:
Longview, TX
Manufacturer:
Hardinge lathes
Model:
DV59

Specifications

Condition:
used
Serial number:
7950
Stock number:
2231
Division:
Metalworking
Electrics:
230V/3PH/60HZ, 1 H, Control Voltage 110/1/60
Bar capacity:
1 -1/16”
New (approx.):
1962
Swing over bed:
Swing over cross slide:
4.5”
Spindle speeds (variable):
230-1300 Low, 460 – 2500 High
Distance of spindle to turret:
3” – 18”

Description

Specifications:
Model: DV59
S/N: 7950
New (Approx.): 1962
Bar Capacity: 1 -1/16”
Swing Over Bed: 9”
Swing Over Cross Slide: 4.5”
Distance of Spindle to Turret: 3” – 18”
Spindle Hardinge Taper
Spindle Speeds (Variable): 230-1300 Low, 460 – 2500 High
Electrics: 230V/3PH/60HZ, 1 H, Control Voltage 110/1/60
Equipped With:
Variable Speed Motor
6 Position Turret
Coolant
Cross Slide Tool Holder
Collet Set 1/8 – 1” 15 Pcs. (NEW) 5C
Box Turning Tool
Two Drill Chucks
Coolant Pump (TMSI will order one for this machine and install before shipment)
