Swing over main slide 12"
Maximum length from spindle to center 6"
Maximum wheel diameter 4"
Longitudinal travel on main slide 5-3/4"
Cross travel of main slide 5-1/4"
Maximum turntable swivel of workhead 235 degrees
Workhead spindle speed 436 rpm
Wheelhead spindle speeds 4000, 5729, 8000 rpm
Wheelhead motor 1/3 HP
Shipping dimensions (L x W x H) 34" x 55" x 62"
Weight approximate 1500 lbs.
Large cutter radius grinding attachment, Adjustable stock support,
Internal grinding attachment, Toothrest, Ajustable tail-center support,
Spring loaded index pawl for workhead, Guards for grinding wheel,
Assorted collets, Assorted Universal Engineering flex collets,
Index plate with 12 divisions, Micrometer stops, Bijur lube system
