Location:
Lincolnwood, IL
Manufacturer:
Pfauter
Weight:
30,000 lbs

Specifications

Condition:
used
Year:
1966
Serial number:
21148
Stock number:
gh906
Shifting:
240mm, 9.44"
Gear width:
580mm, 22.8"
Module max:
12
Hob diameter:
220mm, 8.66"
Machine weight:
30,000 lbs
Table diameter:
950mm, 37.4"
Cutter length max:
260mm, 10.2"
Table bore diameter:
200mm, 7.87"
Wheel diameter, max:
1250mm, 49.2"
Total power requirement:
20kW
Length of teeth cutting, max:
500-580mm, 19.7-22.8"
Electrical control cabinet dimensions:
17" x 64" X 71"H
Machine dimensions without control cabinet:
161"LR x 74"FB x 100" H
Subcategory:
Gear
Subcategory 2:
Hobber

Description

Equipped With:
Universal Hob Head. Automatic Hob Shifting. Radial Feed. Differential. Radial And Axis Rapid Traverse. Power Clamping. Stepless Hob Speed Control. Stepless Feed Control. Miscellaneous Change Gears.
