Location:
Lincolnwood, IL
Manufacturer:
Rousselle presses
Capacity:
80 Tons
Stroke:
3"

Specifications

Condition:
used
Year:
1973
Serial number:
19619
Stock number:
pp15164x
Motor:
7.5 HP, 3/60
Speed:
75 SPM
Stroke:
3"
Area of bed:
80" LR x 30" FB
Area of slide:
74" LR x 20" FB
Opening in bed:
65" LR x 14" FB
Ram adjustment:
4"
Tonnage capacity:
80 Tons
Approximate weight:
13,000 lbs
Opening between uprights:
14" LR
Shut height to bed (sdau):
16.75"
Distance floor to top of bed:
32"
Overall dimensions (approximate):
120" LR x 72" FB x 108"H
Subcategory:
Ssdc

Description

Equipped With:
Air Clutch and Brake/Air Counterbalance to Slide. Dual Operator Stations w/ Dual Palm Button Operation and E-Stop Buttons on Each. 3" Thick Bolster Plate. Wintriss Brake Monitor. Stroke Selector for: Off-Inch-Single-Continuous. One-Shot Lubrication System. Motorized Ram Adjustment. Pushbuttons for: Forward/Reverse. Gemco Rotary Limit Switch. Air Surge Tank.
