Location:
Indian Trail, NC
Model:
G60-FX
Spindle Diameter:
6"

Specifications

Condition:
used
Year:
1980
Serial number:
455-17-80
Stock number:
1621
Clamping:
Air
Work height:
11.75"
Feeds, w-axis:
1-120 IPM
Feeds, z-axis:
.1-200 IPM
Spindle taper:
#50
Rapid traverse:
320 IPM
Infeed of tables:
59"
Spindle diameter:
6"
Feeds, x & y axes:
.1-300 IPM
Number of t-slots:
6
Rotary table size:
48" x 72"
Shot pin locations:
4 x 90 Degrees
Column travel, x-axis:
288"
Table weight capacity:
25,000 LBS
Spindle travel, z-axis:
48"
Spindle speeds, variable:
25-1120 RPM
Distance between t-slot centers:
8"
Vertical headstock travel, y-axis:
108"
G&l rotary table on infeeding slides:
Age: 2001

Description

Equipped With:
Giddings & Lewis 8000M CNC Control (New 2002), 40 Station Automatic Tool Changer, Power Draw Bar, Flood & Mist Coolant, Hardened Runway Ways, Roll-Up Way Covers for Runway, Double Anti-Backlash Rack and Pinion on X Axis, Lubricool System, 3-Way Column, 40 HP Spindle Drive 460/3/60 Cycle, FACING HEAD SHOWN MOUNTED TO MACHINE NOT AVAILABLE
