Location:
Indian Trail, NC
Model:
WT-300MMYS

Specifications

Condition:
used
Year:
2005
Serial number:
M300608
Stock number:
1762
Bar capacity:
2.55"
Spindle bore:
3.1"
Spindle nose:
A2-6
Spindle horsepower:
20 HP
Spindle speed range:
50-4500 RPM
Max turning capacity:
10.6"
C-axis on both spindles:
.001 Degree
Live tooling horsepower:
5 HP
B-axis sub-spindle slide:
33.46"
Live tooling speed range:
90-4000 RPM
Max swing over slant bed:
12.2"
Approximate machine height:
89"
Approximate machine weight:
28,000 lbs.
Approximate machine dimensions:
166"x 100"
Max machinable center distance:
30.7"
Y-axis travel upper turret only:
2.36"
Cross travel (x-axis) lower turret:
7.6"
Cross travel (x-axis) upper turret:
7.6"
Tool positions (12 on each turret):
24 Total
Longitudinal travel (z-axis) lower turret:
30.7"
Longitudinal travel (z-axis) upper turret:
30.7"
Subcategory:
Lathes cnc

Description

Equipped With:
Fanuc 18iTB CNC Control*Upper and Lower Turrets*Live Tooling in Both Turrets*Y-Axis on Upper Turret*Main Spindle and Sub-Spindle*C-Axis on Both Spindles*LNS S3 Bar-Feeder*Parts Catcher*Chip Conveyor and Coolant System*Tooling Package Including 3 Driven Tools and 11 Static Holders
