Location:
Navasota, TX
Manufacturer:
Ceruti
Model:
ABC-75

Specifications

Condition:
used
Stock number:
B550041
Rapids:
98.5 IPM
Weight:
14,100 Lbs.
Main motor:
10 Hp.
Table load:
5,500 Lbs.
Floor space:
8' Wide X 13' Long
Table feeds:
.0009 To .160 IPR
Spindle size:
3"
Spindle feeds:
.001 To .250 I.P.R.
Spindle taper:
# 5
Condition info:
Good
Machine height:
8'
Spindle travel:
23.6"
Rotary table size:
33.4" X 43.3"
Table travel cross:
48"
Spindle speeds main:
15 To 1,500 Rpm's
Saddle travel in & out:
39"
Spindle head travel up & down:
31.5
Subcategory:
Table type

Description

Specification Description
Spindle Size 3"
Spindle Taper # 4
Spindle Speeds Main 15 To 1,500 Rpm,s
Spindle Feeds .001 To .250 I.P.R.
Spindle Travel 23.6"
Spindle Head Travel Up & Down 39"
Saddle Travel In & Out 39"
Rotary Table Size 33.4" X 43.3"
Table Travel Cross 55"
Table Load 4,000 Lbs.
Main Motor 10 Hp.
Floor Space 7' Wide X 13' Long
Machine Height 8'
Rapids Yes
Note: Machine Will Be Cleaned And Cycled.
Condition Good
