Location:
Navasota, TX
Model:
300 T

Specifications

Condition:
used
Year:
1951
Serial number:
Fasct 1094
Stock number:
B550052
Rapids:
Yes
Main motor:
10 Hp.
Table size:
30" X 48"
Saddle feeds:
.5 To .250 IPR
Spindle size:
3"
Spindle feeds:
.002 To .062 IPR
Spindle taper:
#4 Morse
Condition info:
Very Good
Spindle speeds:
22 To 1,000 Rpm
Spindle travel:
14"
Condition info 2:
Good
Table travel cross:
38"
Rotary table size g&l:
30" X 30"
Saddle travel in & out:
51"
Spindle head travel up & down:
42"
Threading (less change gears):
2 To 28 TPI
Subcategory:
Table type

Description

Specification Description
Spindle Size 3"
Spindle Taper #4 Morse
Spindle Speeds 22 To 1,000 Rpm
Spindle Feeds .002 To .062 IPR
Saddle Feeds .5 To .250 IPR
Spindle Travel 14"
Spindle Head Travel Up & Down 42"
Saddle Travel In & Out 51"
Table Size 30" X 48"
Rotary Table Size G&L 30" X 30"
Table Travel Cross 38"
Threading (Less Change Gears) 2 To 28 TPI
Main Motor 10 Hp.
Rapids Yes
Note: Machine Has Just Been Removed From
Service And Is On The Way In. It Will Be Cleaned,
Painted And Cycled.
Condition Very Good
