Location:
Navasota, TX
Model:
65
Weight:
8,000 Lbs.

Specifications

Condition:
used
Year:
1955
Serial number:
S65278
Stock number:
G802510
Main motor:
10 Hp. 220 / 440
Table size:
12" X 53"
Cross travel:
14"
Longitudinal:
55"
Condition info:
Very Good
Machine height:
96"
Approximate weight:
8,000 Lbs.
Coolant tank & pump:
Yes
Magnetic chuck size:
12" X 48"
Vertical working height:
14"
Rapid traverse up & down:
Yes
Floor space front to back:
80"
Floor space right to left:
136"
Grinding wheel speeds low / high:
1,800 & 2,140 Rpm's
Eelectromatic neutrofier for chuck:
Yes
Standard grinding wheel high speed:
11" X1"X3"
Standard size grinding wheel low speed:
14" X1"X3"
Subcategory:
Grinders

Description

Specification Description
Table Size 12" X 53"
Magnetic Chuck Size 12" X 48"
Longitudinal 55"
Cross Travel 14"
Vertical Working Height 14"
Standard Size Grinding Wheel Low Speed 14" X1"X3"
Standard Grinding Wheel High Speed 11" X1"X3"
Grinding Wheel Speeds Low / High 1,800 & 2,140 Rpm's
Main Motor 10 Hp. 220 / 440
Coolant Tank & Pump Yes
Eelectromatic Neutrofier For Chuck Yes
Rapid Traverse Up & Down Yes
Approximate Weight 8,000 Lbs.
Floor Space Right To Left 136"
Floor Space Front To Back 80"
Machine Height 96"
Note: Machine Will Be Cleaned, Painted And
Cycled. Machine Was On Government Stand-By
Condition Very Good
