Location:
Navasota, TX
Model:
16
Spindle Nose:
L-1

Specifications

Condition:
used
Stock number:
L3000151
Feeds:
.290 To .187 I.P.R.
Height:
60"
Weight:
6,850 Lbs
Chuck size:
12" 3-Jaw
Main motor:
10 Hp.
Coolant pan:
Yes
Floor space:
120" X 55"
Steady rest:
No
Thread dial:
Yes
Spindle hole:
1-3/4"
Spindle nose:
L-1
Threads inch:
1 To 64 T.P.I.
Condition info:
Good
Spindle speeds:
14 TO 1,160 Rpm's
Threads metric:
No
Center distance:
40"
Tail stock taper:
# 4 Morse
Taper attachment:
Yes
Swing over bed ways:
16-1/2"
Swing over cross slide:
10-5/8"
Hardened and ground way:
Yes
Tail stock quill travel:
6-1/2"
Tail stock quill diameter:
2-5/8"
Subcategory:
Engine

Description

Specification Description
Swing Over Bed Ways 16-1/2"
Swing Over Cross Slide 10-5/8"
Center Distance 40"
Spindle Hole 1-3/4"
Spindle Speeds 14 TO 1,160 Rpm's
Spindle Nose L-1
Chuck Size 12" 3-Jaw
Feeds .290 To .187 I.P.R.
Threads Inch 1 To 64 T.P.I.
Threads Metric No
Tail Stock Quill Diameter 2-5/8"
Tail Stock Quill Travel 6-1/2"
Tail Stock Taper # 4 Morse
Steady Rest No
Main Motor 10 Hp.
Weight 6,850 Lbs
Floor Space 120" X 55"
Height 60"
Coolant Pan Yes
Taper Attachment Yes
Thread Dial Yes
Hardened And Ground Way Yes
Note: Machine Has Been Cleaned, Painted & Cycled.
Condition \Good
