Location:
Navasota, TX
Manufacturer:
Demoor
Spindle Nose:
A-15

Specifications

Condition:
used
Stock number:
L410624
Weight:
18,000 Lbs.
Chip pan:
Yes
Feeds long:
.0023 To .1020 IPR
Main motor:
30 Hp.
Feeds cross:
.0019 To .031 IPR
Thread dial:
Yes
Spindle hole:
6"
Spindle nose:
A-15
Threads inch:
7/16" TO 64 TPI
Condition info:
Good
Machine height:
73-1/2"
Spindle speeds:
25 To 900 Rpm's
Threads metric:
1 To 110 MM
Center distance:
120"
Tail stock taper:
#5 Morse
Taper attachment:
Yes
Machine floor space:
80" X 220"
Swing over bed ways:
36"
Push button controls:
Yes
Swing over cross slide:
27.5
Weight between centers:
13,000 Lbs.
Chuck size with 6" hole:
24" 4--Jaw
Steady rest roller type:
11"
Tail stock quill travel:
12"
Chuck size with 6" hole 2:
20" 3 Jaw
Tail stock quill diameter:
4"
Subcategory:
Hollow spindle

Description

Specification Description
Swing Over Bed Ways 36"
Swing Over Cross Slide 27.5
Center Distance 120"
Weight Between Centers 13,000 Lbs.
Spindle Hole 6"
Spindle Speeds 25 To 900 Rpm's
Spindle Nose A-15
Chuck Size With 6" Hole 24" 4--Jaw
Chuck Size With 6" Hole 20" 3 Jaw
Feeds Long .0023 To .1020 IPR
Feeds Cross .0019 To .031 IPR
Threads Inch 7/16" TO 64 TPI
Threads Metric 1 To 110 MM
Tail Stock Quill Diameter 4"
Tail Stock Quill Travel 12"
Tail Stock Taper #5 Morse
Main Motor 30 Hp.
Weight 18,000 Lbs.
Machine Floor Space 80" X 220"
Machine Height 73-1/2"
Steady Rest Roller Type 11"
Chip Pan Yes
Taper Attachment Yes
Thread Dial Yes
Push Button Controls Yes
Note: Machine Will Be Cleaned, Painted & Cycled.
Condition Good
