Location:
Navasota, TX
Model:
3500 lot 64
Spindle Nose:
A-15

Specifications

Condition:
used
Year:
1969
Serial number:
2345549
Stock number:
L63049
Weight:
15,000 Lbs.
Coolant:
Yes
Chuck size:
21" 3 - Jaw
Feeds long:
.005 To .167 I.P.R.
Main motor:
40/20 Hp. 480 Volts
Feeds cross:
.0025 To .082 I.P.R.
Floor space:
180" L. X 83" W.
Spindle hole:
4-3/4"
Spindle nose:
A-15
Condition info:
Good
Flange holders:
4
Machine height:
64"
Spindle speeds:
12 To 829 Rpm's
Center distance:
43"
Condition info 2:
Very Good
Swing over bed ways:
23-1/2"
Tool post 4 way on front:
Yes
Cross sliding rear turret:
No
Rapid traverse front and rear:
Yes
Swing over cross slide carriage:
18"
Subcategory:
Turret saddle type

Description

Equipped With:
Note: Machine Will Have Rear Aprons And Rapid Traverse Box Reconditioned. Rapid Traverse Drive Box Reconditioned, New Bearings, In Main Motor. New Feed And Rapid Shafts. Headstock Cleaned And Flushed, New Filters And Oil. New 21"-4Jaw Gator Chuck W/ Reconditioning. Machine Has Been Cleaned, Painted And Cycled. Machine May Be Seen Under Power With Proper Notice.
