Location:
Navasota, TX
Model:
3500 Lot 703
Spindle Nose:
A-15

Specifications

Condition:
used
Year:
1975
Serial number:
2668088
Stock number:
L630435
Weight:
15,000 Lbs.
Coolant:
Yes
Chuck size:
21" 3-Jaw
Feeds long:
.005 To .167 I.P.R.
Main motor:
30 Hp. 440
Feeds cross:
.0025 To .082 I.P.R.
Floor space:
180" L. X 3" W.
Slide tools:
2
Spindle hole:
6-1/4"
Spindle nose:
A-15
Condition info:
Very Good
Flange holders:
3
Machine height:
64"
Spindle speeds:
24 To 851 Rpm's
Center distance:
43"
Fixed rear turret:
Yes
Power wrench chuck:
Yes
Swing over bed ways:
23-1/2"
Threads less lead screw:
1 To 36 TPI
Tool post 4 way on front:
Yes
Rapid traverse front and rear:
Yes
Swing over cross slide carriage:
18"
Subcategory:
Turret saddle type

Description

Equipped With:
Note: Machine Will Have Rear Aprons And Rapid Traverse Box Reconditioned. Rapid Traverse Drive Box Reconditioned, New Bearings In Main Motor. Headstock Cleaned And Flushed, New Filters And Oil. New 21"-4Jaw Gator Chuck W/ Reconditioning. Machine Will Been Cleaned, Painted And Cycled. Machine May Be Seen Under Power With Proper Notice.
