Location:
Navasota, TX
Model:
4A -1550
Spindle Nose:
A-20

Specifications

Condition:
used
Year:
1953
Serial number:
1292163
Stock number:
L630410
Height:
72"
Weight:
25,000 Lbs.
Coolant:
Yes
Feeds long:
.005 To .167 I.P.R.
Main motor:
20/40 Hp. 440 Volts
Feeds cross:
.0035 To .167 I.P.R.
Floor space:
21' X 7'
Spindle hole:
12-1/4"
Spindle nose:
A-20
Condition info:
Very Good
Flange holders:
3
Spindle speeds:
10 To 210 Rpm's
Center distance:
62"
Fixed rear turret:
Yes
Slide tool holders:
1
Rapid traverse rear:
Yes
Swing over bed ways:
28-1/4"
Chuck size (new heavy duty):
24" 4-Jaw New Gator
Swing over cross slide carriage:
22"
Subcategory:
Turret saddle type

Description

Equipped With:
Note: Machine Rear Apron And Rapid Traverse Box Reconditioned. New Feed And Rapid Shafts. Head Stock Has Been Flushed And New Oil And Filters. Machine Has Been Cleaned, Painted And Cycled. Machine May Be Seen Under Power With Proper Notice
