Location:
Navasota, TX
Model:
4A - 3550 Lot 870
Spindle Nose:
A-15

Specifications

Condition:
used
Year:
1981
Serial number:
3017927
Stock number:
L630417
Height:
80"
Weight:
24,000 Lbs.
Coolant:
Yes
Feeds long:
.005 To .167 I.P.R.
Main motor:
75 Hp.
Feeds cross:
.0035 To .167 I.P.R.
Floor space:
20' X 7'
Spindle hole:
9-1/4"
Spindle nose:
A-15
Condition info:
Very Good
Flange holders:
4
Spindle speeds:
20 To 526 Rpm's
Center distance:
62"
Swing over bed ways:
28-1/4"
Tool post 4 way on front:
Yes
Cross sliding rear turret:
Yes
Chuck size (new heavy duty):
24" 4 - Jaw Gator
Rapid traverse front and rear:
Yes
Swing over cross slide carriage:
22"
Subcategory:
Turret saddle type

Description

Equipped With:
Note: Machine Has Been Cleaned, Painted And Cycled. Ways Have Been Ground And Carriages Refitted And Recondition, Rapid Traverse Have Been Reconditioned, Rapid Drive Angle Box Reconditioned New Feed And Rapid Shafts. New Nut And Screws In Screw Slides And Cross Sliding Hex Turret.
