Location:
Navasota, TX, USA
Model:
4A - 3550 Lot 41
Spindle Nose:
A-15

Specifications

Condition:
used
Year:
1966
Serial number:
2158095
Stock number:
L630418
Height:
80"
Weight:
24,000 Lbs.
Coolant:
Yes
Chuck size:
24" 3-Jaw
Feeds long:
.005 To .167 I.P.R.
Main motor:
75 / 37.5 Hp.
Feeds cross:
.0035 To .167 I.P.R.
Floor space:
22' X 7'
Spindle hole:
9-1/4"
Spindle nose:
A-15
Condition info:
Very Good
Flange holders:
5
Spindle speeds:
20 To 526 Rpm's
Center distance:
124"
Side tool holder:
1
Power wrench chuck:
Yes
Swing over bed ways:
28-1/4"
Tool post 4 way on front:
Yes
Cross sliding rear turret:
Yes
Taper attachment rear apron:
Yes
Swing over cross slide carriage:
22"
Rapid traverse front & rear carriages:
Yes
Chuck size (new gator heavy duty not pictured):
25" 4-Jaw
Subcategory:
Turret saddle type

Description

Equipped With:
Note: Machine Will Have Both Aprons And Rapid Traverse Boxes Reconditioned. New Feed And Rapid Shafts.Rapid Drive Box Reconditioned, Head Stock Will Be Flushed And New Oil And Filters. Machine Will Be Cleaned, Painted And Cycled. Machine May Be Seen Under Power With Proper Notice
