Location:
Navasota, TX
Model:
4A - 3580 Lot 16
Spindle Nose:
A-15

Specifications

Condition:
used
Year:
1960
Serial number:
1577719
Stock number:
L630462
Rapids:
Yes
Weight:
22,000 Lbs.
Coolant:
Yes
Feeds long:
.005 To .167 I.P.R.
Main motor:
60 /30 Hp
Feeds cross:
.004 To .090 I.P.R.
Spindle hole:
12-1/2
Spindle nose:
A-15
Condition info:
Very Good
Machine height:
80"
Spindle speeds:
20 To 526 Rpm's
Center distance:
62"
Swing over ways:
28-1/4"
Long flange holders:
1
Short flange holder:
2
Threading front & rear:
1 To 36 TPI
Tool post 4 way on front:
Yes
Cross sliding rear turret:
Yes
Floor space front to back:
7'
Floor space right to left:
20'
Full chip pan and coolant:
Yes
Chuck size (new heavy duty):
24" 4 Jaw New Gator
Swing over cross slide carriage:
22"
Taper attachment on rear turret:
Yes
Subcategory:
Turret saddle type

Description

Equipped With:
Note: Machine Will Have Both Aprons And Rapid Traverse Boxes Reconditioned. New Feed And Rapid Shafts. Head Stock Flushed And New Oil And Filters. Machine Will Be Cleaned, Painted And Cycled. Machine May Be Seen Under Power With Proper Notice.
