Location:
Elk Grove Village, IL
Model:
618 Automatic
Weight:
1,500 Lbs.

Specifications

Condition:
used
Year:
1985
Serial number:
6223H
Stock number:
2989
Motor:
1 HP
Volts:
208/220/440V
Electrics:
3 phase/ 60 Hertz
Cross travel:
6-3/4"
Approx weight:
1,500 Lbs.
Condition info:
Good
Approx dimensions:
71" x 45"
Longitudinal travel:
18-3/4"
Width & length ground:
6" x 18"
Longitudinal table speed:
0 to 70' FPM
Grinding wheel dimensions:
7" x 1/2" x 1-1/4"
Working height under wheel:
11-3/4"
Cross feed increment per table pass:
Yes
Subcategory:
Grinders
Subcategory 2:
Horizontal surface

Description

Equipped With:
Hydraulic Table Traverse, Auto Electro-Mechanical Power Cross Feed ( controlled by thumb switches, Coolant System, 6" x 18" Walker Electro-Magnetic Chuck, Walker Auto. Chuck Control w/ Variable Holding & Auto Demag
