Location:
Contamine-sur-Arve, France
Manufacturer:
Hauser boring mills
Model:
B3-DR
Spindle Diameter:
85 [mm]

Specifications

Condition:
used
Serial number:
B30230
Stock number:
P999
Power:
8.2 [kW]
Weight:
2800 [kg]
Dimensions:
1330 x 1700 x 2545 (H) [mm]
Strokes x x y:
400 x 250 [mm]
Surface table:
600 x 380 [mm]
Boring capacity:
Ø 220 [mm]
Loading capacity:
max. 300 [kg]
Spindle diameter:
85 [mm]
Drilling capacity:
Ø 30 [mm]
Internal spindle cone:
ISO 30
Distance spindle nose - table:
550 [mm]
Subcategory:
Boring
Subcategory 2:
Jig boring machine

Description

TECHNICAL DETAILS
Strokes X x Y : 400 x 250 [mm]
Distance spindle nose - table : 550 [mm]
Drilling capacity : Ø 30 [mm]
Boring capacity : Ø 220 [mm]
Surface table : 600 x 380 [mm]
Loading capacity : max. 300 [kg]
Internal spindle cone : ISO 30
Spindle diameter : 85 [mm]
Power : 8.2 [kW]
Dimensions : 1330 x 1700 x 2545 (H) [mm]
Weight : 2800 [kg]

EQUIPMENT
3 axis display ELESTA Visulesta II
Rotary table dia. 300 ref 162332
Attachment table 300x300 mm for rotary table ref 169345
Indexing system ref 166250
Adjustable device for contour measurement ref 166378
Boring head UPA 3, capacity Ø 5-220 mm ref 169833
Boring head 31, capacity Ø 0.5-30 mm ref 169829
Boring head 32, capacity Ø 5-60 mm ref 169830
Boring head 33, capacity Ø 5-110 mm ref 169831
Boring head 34, capacity Ø 5-170 mm ref 169832
Micrometric Boring head, capacity Ø 32-40 mm ref 018044
Micrometric Boring head, capacity Ø 40-50 mm ref 018045
Dust extractor ref 162328
Splash Guard on articulated arm ref 165820
Machine Lamp ref 130951
Tool cabinet
Chucks set
Collets set
Clamping elements miscellaneous
