Location:
Contamine-sur-Arve, France
Model:
3SMO
Weight:
1 540 [kg]

Specifications

Condition:
used
Year:
1975
Serial number:
SERIE10862036
Stock number:
5187
Weight:
1 540 [kg]
1 motor:
5 000 – 40 000 [rpm]
1 turbine:
100 000 [rpm]
Dimensions:
2 200 x 1 600 x 2 700 [mm]
Installed power:
6.6 [KW]
Table dimensions:
595 x 320 [mm]
Strokes x x y x z:
400 x 250 x 500 [mm]
1 motor high speed:
40 000 – 80 000 [rpm]
Maxi weight on table:
200 [kg]
Grinding spindle stroke:
110 [mm]
Rotation speed with motor:
9 000 – 80 000 [rpm]
Rotation speed with turbine:
225 000 [rpm]

Description

TECHNICAL DETAILS
table dimensions : 595 x 320 [mm]
maxi weight on table : 200 [kg]
strokes X x Y x Z : 400 x 250 x 500 [mm]
distance spindle nose and table surface : 655 [mm]
grinding spindle stroke : 110 [mm]
rotation speed with motor : 9 000 – 80 000 [rpm]
rotation speed with turbine : 225 000 [rpm]
installed power : 6.6 [KW]
dimensions : 2 200 x 1 600 x 2 700 [mm]
weight : 1 540 [kg]

EQUIPMENT
1 divisor plate Ø 300 [mm]
1 motor high speed: 40 000 – 80 000 [rpm]
1 motor: 5 000 – 40 000 [rpm]
1 turbine: 100 000 [rpm]
1 alignment rest with lighting
1 support indicator
6 grinding wheel holders
1 set of 7 collets Ø 3 to 10 [mm]
