Location:
Contamine-sur-Arve, France
Model:
600 U-175
Weight:
2250 [kg]

Specifications

Condition:
used
Year:
1982
Stock number:
6837P
Weight:
2250 [kg]
Centers height:
175 [mm]
Table orientation:
11°
Part holder motor power:
0.9 [KW]
Distance between centers:
600 [mm]
Part holder spindle speed:
20 – 400 [rpm]
Grinding wheels dimensions:
400 x 50 x 127 [mm]
Dimensions (length x width):
3100 x 2000 [mm]
Counter headstock internal cone:
Morse 3
Counter headstock sleeve stroke:
30 [mm]
Part holder headstock orientation:
360 [°]
Part holder spindle internal cone:
Morse 5
Grinding wheel holder spindle speed:
1500 [rpm]

Description

TECHNICAL DETAILS
distance between centers : 600 [mm]
centers height : 175 [mm]
table orientation : 11°
grinding wheel holder slide maxi stroke : 285 [mm]
grinding wheels dimensions : 400 x 50 x 127 [mm]
grinding wheel holder headstock motor power : 3 [kW]
grinding wheel holder spindle speed : 1500 [rpm]
part holder headstock orientation : 360 [°]
part holder spindle speed : 20 – 400 [rpm]
part holder spindle internal cone : Morse 5
part holder motor power : 0.9 [KW]
counter headstock internal cone : Morse 3
counter headstock sleeve stroke : 30 [mm]
dimensions (length x width) : 3100 x 2000 [mm]
weight : 2250 [kg]

EQUIPMENT
display HEIDENHAIN 2 axis
lubricating tank with paper filter
wheel balancing device
various flanges (right and left)
inner grinding spindle Ø 70 mm
angular grinding wheel trueing device
trueing device for inside grinding spindle
rest 2 points
fixed rest
3 jaws chuck
magnetical chuck
