2008 Parkson PAR-250 CNC Tilting
Location:
Hornberg, Germany
Manufacturer:
Parkson
Model:
PAR-250
Weight:
350

Specifications

Condition:
used
Year:
2008
Stock number:
70009
Condition info:
DISPLAY ITEM
Repeatability sec:
2
Width of t-slot mm:
12H7
Repeatability sec 2:
3
Indexing accuracy sec:
15
Table top diameter mm:
250
Indexing accuracy sec 2:
45
In tilt (0~90 degree) kg:
75
Through hole diameter mm:
64
Max. rotation speed r.p.m:
16.7-11.1
Indexing resolution degree:
0.001
Tilting angle range degree:
110
Net weight of table w/o servo motor kg:
350

Description

Table Top Diameter mm: 250
Through Hole Diameter mm: 64
Width of T-slot mm: 12H7
Indexing Resolution degree: 0.001
Tilting Angle Range degree: +/- 110
Max. Rotation Speed r.p.m : 16.7-11.1
Max. Load: In Horizontal kg: 100
In Tilt (0~90 degree) kg: 75
Rotary Axis: Brake Torque kg-m: Pneumatic 6 kg/quadratcm: 30
Indexing Accuracy sec: 15
Repeatability sec. : +/- 2
Tilt Axis: Brake Torque kg-m: Pneumatic 6 kg/quadratcm: 72
Indexing Accuracy sec: 45
Repeatability sec. : +/- 3
Net Weight of Table W/O Servo Motor kg: 350
