Location:
Staufenberg, Germany
Manufacturer:
PARX
Model:
KRS 2

Specifications

Condition:
used
Year:
1973
Stock number:
17085
Subcategory:
Shearing

Description

Fully hydraulic cam roller scissors Fabr. PARX type KRS 2
: 3728 Series 61/72, built in 1973
Technical specifications:
Shear performance b. 40 kg / mm2 strength: 6 mm
Shear performance b. 70 kg / mm2 strength: 4 mm
Throat btw stand and knife. 1050 mm
Stand jaw height: 300 mm
kl. Turning radius: 75 mm
kl. Rondendrm .: 290/180 mm
Max. Rondendrm. 4-eck Bleck: 2750 mm
min. Bördeldrm .: 450 mm
Max. Flaring: 50 mm
Max. Bördelradius: 35 mm
Cutting speed continuously: 0 - 12 m / min.
Power demand: 6 PS
Weight: 1.85 t (without Dornzentrierung)
External dimensions: 3000 x 900 x 2000 mm
: (Without Dornzentrierung)
With
- Fully hydraulic. drive
- Stufenl. Speed ​​control
- Const starting and operating torque.
- Automatic workpiece feeding
- Contour cutting (trimming)
- Circular cut
- Spiral cut
- Beading
- With verstellb. Dornzentrierung
needed from operating resolution, in good condition
Price on request.
Delivery: from stock or store freely loaded truck.
Payment: at acquisition, net or ...
