Location:
Navasota, TX
Model:
3KVHD
Spindle Taper:
R- 8

Specifications

Condition:
used
Year:
1997
Serial number:
97022
Stock number:
M282434
Height:
84-5/8"
Weight:
3,350 Lbs.
Main motor:
3 Hp.
Table size:
10" X 50"
Knee travel:
15"
T-slot size:
5/8"
Spindle tilt:
+/- 45 Degrees
Spindle feeds:
.001 To .003 I.P.R.
Spindle taper:
R- 8
Condition info:
Good
Spindle swivel:
+/- 90 Degrees
Over arm swivel:
360 Degrees
T-slots on table:
3
Spindle speeds low:
50 To 3,750Rpm's
Power feed on table:
Yes
Spindle quill travel:
5"
Table feeds variable:
0 To .250 I.P R.
Table weight capacity:
946 Lbs.
Saddle travel in & out:
15-3/4"
Floor space front to back:
79"
Floor space right to left:
101-1/4"
Table travel longitudinal:
30-3/4"
Over arm travel in and out:
21-5/8"
Spindle to table min. / max:
1-5/8" To 16-1/2"
Spindle speeds variable high:
60 To 4,500 Rpm's
Spindle centerline to column min. / max:
4" To 25-5/8"
Subcategory:
Mills
Subcategory 2:
Knee type

Description

Table Size 10" X 50"
Table Weight Capacity 946 Lbs
T-Slots On Table 3
T-Slot Size 5/8"
Spindle Taper R- 8
Spindle Speeds Low 50 To 3,750Rpm's
Spindle Speeds Variable High 60 To 4,500 Rpm's
Spindle Feeds .001 To .003 I.P.R.
Spindle Quill Travel 5"
Spindle Tilt +/- 45 Degrees
Spindle Swivel +/- 90 Degrees
Spindle To Table Min. / Max 1-5/8" To 16-1/2"
Spindle Centerline To Column Min. / Max 4" To 25-5/8"
Saddle Travel In & Out 15-3/4"
Table Travel Longitudinal 30-3/4"
Knee Travel 15"
Table Feeds Variable 0 To .250 I.P R.
Over Arm Travel In And Out 21-5/8"
Over Arm Swivel 360 Degrees
Main Motor 3 Hp.
Weight 3,350 Lbs.
Floor Space Right To Left 101-1/4"
Floor Space Front To Back 79"
Height 84-5/8"
Power Feed On Table Yes
Note: Machine Will Be Cleaned And Cycled.
Machine May Be Seen Under Power With Proper
Notice
Condition Good
