Location:
Holland, OH, USA
Price:
No price
Manufacturer:
Grindingmaster
Model:
MCSB-900

Specifications

Condition:
used
Serial number:
RK15023
Stock number:
51230
2-speed conveyor:
23 AND 46 FPM
Pneumatic tracking:
YES
Maximum part thickness:
6"
Width of conveyor belt:
36"
Width of grinding belt:
36" (930 MM)
Length of grinding belt:
75" (1900 MM)
Diameter of contact roll:
10"
Conveyor belt motor, horsepower:
3/4, 1-1/4
Grinding head motor, horsepower:
24
Power vertical table adjustment:
YES
Table adjustment motor, horsepower:
1/2
Subcategory:
Belt
Subcategory 2:
Grinder

Description

SERIAL .............................. RK15023
MODEL ............................... MCSB-900
WIDTH OF GRINDING BELT .............. 36" (930 MM)
WIDTH OF CONVEYOR BELT .............. 36"
MAXIMUM PART THICKNESS .............. 6"
DIAMETER OF CONTACT ROLL ............ 10"
2-SPEED CONVEYOR .................... 23 AND 46 FPM
PNEUMATIC TRACKING .................. YES
POWER VERTICAL TABLE ADJUSTMENT ..... YES
LENGTH OF GRINDING BELT ............. 75" (1900 MM)
GRINDING HEAD MOTOR, HORSEPOWER ..... 24
CONVEYOR BELT MOTOR, HORSEPOWER ..... 3/4, 1-1/4
TABLE ADJUSTMENT MOTOR, HORSEPOWER .. 1/2
