Ardcor U-10 in Holland, OH, USA

Top Seller
Ardcor U-10 in Holland, OH
Location:
Holland, OH, USA
Price:
No price
Manufacturer:
Ardcor
Model:
U-10

Specifications

Condition:
used
Stock number:
14013
Tooling:
1.315" ON MILL
Welding:
(2) ROLL WELD PRESSURE
Roll space:
6"
Sizing mill:
(4) DRIVEN SIZING STANDS
Forming mill:
(6) DRIVEN BREAK DOWN STANDS
Worm gear ratio:
14.5:1
Spindle diameter:
2"
Horizontal centers:
16"
Vertical adjustment:
4" - 8-5/8"
Maximum tube diameter:
1-1/2"
Minimum tube diameter:
3/4"
Maximum wall thickness:
.134"
Minimum wall thickness:
.034"
Center of lower spindle to base:
7-1/2"
Category:
Machine Tools equipment in United States
Subcategory:
Tube machinery (all)

Description

MODEL ............................ U-10
MAXIMUM TUBE DIAMETER ............ 1-1/2"
MINIMUM TUBE DIAMETER ............ 3/4"
MAXIMUM WALL THICKNESS ........... .134"
MINIMUM WALL THICKNESS ........... .034"
VERTICAL ADJUSTMENT .............. 4" - 8-5/8"
HORIZONTAL CENTERS ............... 16"
ROLL SPACE ....................... 6"
SPINDLE DIAMETER ................. 2"
CENTER OF LOWER SPINDLE TO BASE .. 7-1/2"
WORM GEAR RATIO .................. 14.5:1
FORMING MILL ..................... (6) DRIVEN BREAK DOWN STANDS
(3) DRIVEN FINE STANDS
+ CHAR(13) + CHAR(10) +
+ CHAR(13) + CHAR(10) +
WELDING .......................... (2) ROLL WELD PRESSURE
SEAM IRONING PASS
SIZING MILL ...................... (4) DRIVEN SIZING STANDS
(4) IDLE SIDE ROLLS
(2) 2-ROLL STRAIGHTENING UNITS
25 HP DC 500 VOLT MOTOR
TOOLING .......................... 1.315" ON MILL
