Location:
Indian Trail, NC
Manufacturer:
Leblond lathes
Model:
NK
Distance between Centers:
228"

Specifications

Condition:
used
Stock number:
1874
Bed width:
31"
Electrics:
3/60/480v
Feeds (48):
0.004-.250 IPR
Main motor:
30 HP
Spindle hole:
2-1/4"
Spindle type:
L3 Threaded
Machine height:
64"
Machine weight:
33,000 lbs.
Threading range:
3/4 to 46 TPI
Machine footprint:
340" x 80"
Cross slide travel:
18"
Spindle speeds (16):
6-315 RPM
Compound rest travel:
5"
Max. swing over bedways:
36"
Distance between centers:
228"
Tailstock spindle diameter:
5"
Max. swing over cross slide:
24"
Tailstock travel and set-over:
9", 1"
Distance spindle center to floor:
44"
Subcategory:
Engine lathes

Description

Equipped With:
Hardened and Ground Bed Ways*Coolant System*Trak 102, 2-Axis Digital Readout System*24" 4-Jaw Chuck*24" 3-Jaw chuck*12" 3-Jaw Chuck*14" Face Plate*Boring Bar Attachment with 6" x 144" Boring Bar*Thread Dial*24" x 14" Roller-Type Steady Rests*Live Center*7" Square 4-Way Toolpost
