Location:
Dundee, FL
Manufacturer:
Cincinnati
Model:
2510G
Capacity:
.375"
Weight:
24,000 lbs

Specifications

Condition:
used
Year:
2000
Force:
11 Tons
Motor:
15 HP
Equipment:
10' Left Hand Squaring Arm w/Swinging Stop 4' Right Hand Squaring Arm w/Swinging Stop Fractional Scales in Table & Squaring Arms (3) Material Support Arms including Disapperaing Stops Digital Gauge Control Ball Transfers in Table Manual Knife Clearance Adjustment Sheet Stacker available for an additional $20k
Knife size:
1"x4"x124"
Strokes per min:
50
Gauge range back:
48"
Max cutting length:
122.5"
Rake (inches/foot):
.281
Mild steel capacity:
.375"
Approx machine weight:
24,000 lbs
Hold downs to knife edge:
11
Distance under hold downs:
.625"
Distance from holdown guard to knife edge:
3.5"
Subcategory:
Conventional
Subcategory 2:
Fabrication machines

Description

10' Left Hand Squaring Arm w/Swinging Stop
4' Right Hand Squaring Arm w/Swinging Stop
Fractional Scales in Table & Squaring Arms
(3) Material Support Arms including Disapperaing Stops
Digital Gauge Control
Ball Transfers in Table
Manual Knife Clearance Adjustment
Sheet Stacker available for an additional $20k
