- Compare this machine to our German friends and give us a call!
- GANG RIP SAW, SHIFTING BLADE(S)
- Condition info:
- Brand New w/Warranty
- Current status:
- Brand New
- 230/460 V, 60 Cy, 3 Ph.
- Appr. repl. cost:
- Rip saws - multi-blade
4.2" Max. cutting thickness without pressure plate, 3.7" with pressure plate; 24" Max. cutting width; 35.4" Max. material width of pass-through; 60 HP Saw motor (larger optional); 2.8" (70mm) Saw arbor diameter turning at 3800 RPM; 12" Min. or 14" max. Sawblade diameter; 2.8" (70mm) Sawblade bore when mounted directly on shaft, 3.5" (90mm) when mounted on saw sleeve; 5 HP feed motor with variable feed speeds from 25 to 200 FPM; 1/2 HP pressure roller raising motor; 24" Min. stock length; 31.9" Min. stock length with board under (2) rollers. __ FEATURES AND BENEFITS: __ The main frame is cast iron, all the main parts are enclosed, ensuring protection and perfect stability __ Nickel chrome steel saw arbor with 70 mm OD double keyed quick removal sleeve __ Heavy duty precision straight line feeding caterpillar chain type __ Feed chain with easily replaceable bolt in cast steel or urethane pads - optional __ The top pressure roller system is electronically positioned from the front control panel with regards to lumber thickness with position readout. __ Top roller hold down system is mated to the servo positioning short stock shoe providing optimum straight line ripping performance and comprehensive safety. __ Pneumatic pressure (infinitely variable) to the holddown feed rollers provides better control of the lumber __ Nickel chrome steel saw arbor __ Variable feed speeds of 16'-200' min. (5-60m/min) via an inverter motor and speed control with led readout __ Electronic overload sensing system is integrated to the inverter feed system providing automatic speed reduction under heavy amperage load __ New - short stock cutting device included __ Digitally controlled lubricator for chain __ Centralized lubrication system __ (2) Powered top & bottom outfeed rollers are a standard feature. The powered roll system facilitates positive flow of the stock through the gang saw and onto outfeed conveyors or transfers __ (3) Rows of anti-kickback fingers __ Telemechanique - automatic star-delta starter (low amperage soft-start) and low voltage controls __ Controls are mounted on the saw for easy convenient machine operation __ Includes 12' infeed table __ Gang saw sleeve is optional extra __ Electrics to 230/460 or 575-volt, 3-phase, 60-cycle to UL/CSA standards __ Complete Shifting Fence Infeed Tables and complete Outfeed Sweep Systems, handling decks and Stacking Systems are available. __ Options available: __ Add for 75 Hp Saw arbor motor in lieu of 60 HP - including Wye-Delta low amp Starter __ 100 HP Saw arbor motor in lieu of 60 HP - including Wye-Delta low amp Starter __ 125 HP Saw arbor motor in lieu of 60 HP - including Wye-Delta low amp Starter __ Short Stock Feeding device (min. length 12" - must use 12 blades for max. thickness of cut of 2.16" (55mm) __ 20MW Laser (FP MLC1320W) & Laser Holder w/12" Bolt on Base-Stand __ As above but with 12" Magnetic Base-Stand in lieu of 6" __ HD Gang Saw Sleeve - 90mm OD __ NEW - Single Blade Mechanical Quick Loc
