2003 BATTENFELD TM 2100-1000 UNILOG
Location:
Langenfeld, Germany
Model:
TM 2100-1000 UNILOG B4
Screw Diameter:
50 mm
Clamping Force:
2100 kN

Specifications

Condition:
used
Year:
2003
Typ:
TM 2100-1000 UNILOG B4
Swebt volume:
491 ccm
Total weight:
8800kg
Warehouse no:
502113
Clamping force:
2100 kN
Opening stroke:
530 mm
Screw diameter:
50 mm
Operating hours:
17855
Type of machine:
Injection molding machines
Machine in stock:
Yes
Max. mould height:
540 mm
Min. mould height:
190 mm
Operating hours 2:
17855 h
Injection pressure:
2016 bar
Year of construction:
2003
Size of mould plates h:
840 mm
Size of mould plates v:
840 mm
Measures of machine lxbxh:
5.58m x 1.64m x 2.25m
Distance between tie bars h:
570 mm
Distance between tie bars v:
570 mm

Description

Injection molding machines BATTENFELD TM 2100-1000 UNILOG B4
used machine
warehouse no.: 502113
manufacturer: BATTENFELD
Typ: TM 2100-1000 UNILOG B4
year of construction: 2003
operating hours: 17855 h
clamping unit
clamping force: 2100 kN
distance between tie bars h: 570 mm
distance between tie bars v: 570 mm
size of mould plates h: 840 mm
size of mould plates v: 840 mm
min. mould height: 190 mm
max. mould height: 540 mm
opening stroke: 530 mm
injection unit
screw diameter: 50 mm
swebt volume: 491 ccm
injection pressure: 2016 bar
equipment
machine with material hopper
Schuko-socket 10A
air valve fixed WAP
core pulling hydraulically 1x
CEE-socket 16A
4x control for hotrunner
Anti vibration mounts
screen text german
machine incl. water flow regulator
measures of machine lxbxh: 5.58m x 1.64m x 2.25m
total weight: 8800kg
