Location:
Nordhorn, Germany
Manufacturer:
Nau-Tank
Model:
upright, on 3 bases

Specifications

Condition:
used
Year:
2009
Contents:
approx. 40 m³ / 40,000 litres
Material:
steel
Year built:
approx 2007
Type of machine:
Thermal store 40,000 litres steel buffer tank
Machine in stock:
Yes
Diameter with insulation:
2.75 m
Diameter without insulation:
approx. 2,50 m

Description

Thermal store 40,000 litres steel buffer tank
used machine
Thermal store / buffertank with a nominal capacity of 40,000 litres on 2 steel bases.
Contents: approx. 40 m³ / 40,000 litres
Material: steel
Diameter with insulation: 2.75 m
Diameter without insulation: approx. 2,50 m
Year built: approx 2007
Buffer in cylindrical shape. Insulated by mineral/glass fibres, 10cm thick. Panels are made of aluminium sheets. The container is in used state, and has been drained and cleaned professionally.
The heat storage tank has a separate connection pair (forward / reverse) for the heat supply (E.g. from CHP, boiler) and heat extraction (e.g. from a heating network). Thus, a real buffering is possible, and a temporary extraction higher than the thermal power of the heat generator, eg. to deal with heat peaks. Optionally and at additional cost more pairs of connection can be installed to connect another heat generator to this buffer. Flanges DN 80 PN6 or alternatively in DN 100 PN6. Operating pressure 1.5 bar. Maximum temperature 90° C.
Price upon request.
This tank is being sold and converted to a heat accumulator by our specialist partner company Natur-Energie-Technik. Transport can be arranged at low cost.
For more information and offers visit our website: profi-tanks(dot)de
