Top Seller
Cincinnati 0230 X 12 MDL
Location:
Holland, OH
Model:
0230 X 12 MDL 230FM10
Stroke:
10"
Capacity:
230 TON

Specifications

Condition:
used
Stock number:
57269
Motor:
30 HORSEPOWER
Serial:
42985
Model 2:
230FM10
Capacity:
230 TON
Year new:
1981
Back gauge:
5C HURCO
Open heights:
17"
Closed height:
7"
Stroke of ram:
10"
Floor standing:
YES
Light curtains:
YES
Ram speed down:
225 IPM
Depth of throat:
8
Ram speed return:
290 IPM
Distance between housings:
10'6"
Cincinnati stroke sequencer:
YES
Overall length of bed and ram:
12'
Electric foot trip & palm buttons:
YES

Description

SERIAL ........................................ 42985
MODEL ......................................... 230FM10
YEAR NEW ...................................... 1981
CAPACITY ...................................... 230 TON
OVERALL LENGTH OF BED AND RAM ................. 12'
DISTANCE BETWEEN HOUSINGS ..................... 10'6"
STROKE OF RAM ................................. 10"
OPEN HEIGHTS .................................. 17"
CLOSED HEIGHT ................................. 7"
DEPTH OF THROAT ............................... 8
RAM & BED MILLED AND DRILLED FOR ANGLES ....... YES
RAM SPEED DOWN ................................ 225 IPM
RAM SPEED RETURN .............................. 290 IPM
BACK GAUGE .................................... 5C HURCO
ELECTRIC FOOT TRIP & PALM BUTTONS ............. YES
CINCINNATI STROKE SEQUENCER ................... YES
FLOOR STANDING ................................ YES
LIGHT CURTAINS ................................ YES
MOTOR ......................................... 30 HORSEPOWER
