Top Seller
Natco 16/H6 16 SPINDLE #H-6
Location:
Holland, OH
Manufacturer:
Natco
Model:
16/H6
Capacity:
(13) 1/4"-20

Specifications

Condition:
used
Stock number:
13302
Serial:
H6-1358
Coolant:
YES
Model 2:
H-6
Column riser:
6"
Spindle motor:
5 HORSEPOWER
Spindle speeds:
(28) 206-2735 RPM
Feed rate range:
1/2" - 30 IPM
Table work area:
17" X 28"
Table adjustment:
10"
Tapping capacity:
(13) 1/4"-20
Drilling capacity:
(16) 5/16" DIA. @ 70 FPM X 2 IPM
Table feed travel:
6"
Number of spindles:
16
Upper driver diameter:
1-1/4"
Inside diameter of head:
24" X 10"
Head flange to table top:
35" MAX. / 19" MIN.
Horsepower hydraulic unit:
1-1/2 HORSEPOWER
Subcategory:
Drills

Description

SERIAL ........................ H6-1358
MODEL ......................... H-6
DRILLING CAPACITY ............. (16) 5/16" DIA. @ 70 FPM X 2 IPM
TAPPING CAPACITY .............. (13) 1/4"-20
NUMBER OF SPINDLES ............ 16
UPPER DRIVER DIAMETER ......... 1-1/4"
HEAD FLANGE TO TABLE TOP ...... 35" MAX. / 19" MIN.
INSIDE DIAMETER OF HEAD ....... 24" X 10"
HEAD CENTER TO COLUMN WAYS .... 8-1/2"
TABLE WORK AREA ............... 17" X 28"
TABLE FEED TRAVEL ............. 6"
TABLE ADJUSTMENT .............. 10"
FEED RATE RANGE ............... 1/2" - 30 IPM
SPINDLE SPEEDS ................ (28) 206-2735 RPM
COLUMN RISER ................... 6"
COOLANT ........................ YES
HEAVY DUTY HYDRAULIC FEED TABLE . YES
SPINDLE MOTOR ................... 5 HORSEPOWER
HORSEPOWER HYDRAULIC UNIT ....... 1-1/2 HORSEPOWER
