Top Seller
Cincinnati 425-20 MODEL # HORIZONTAL
Location:
Holland, OH
Manufacturer:
Cincinnati
Model:
425-20

Specifications

Condition:
used
Stock number:
13666
Serial:
9J44H5P-2
Coolant:
YES
Model 2:
425-20 VERCIPOWER
Area of table:
86-1/2" X 20"
Spindle taper:
#50 NS
Spindle speeds:
(24) 14 TO 1400 RPM
Cross table travel:
18"
Table rapid traverse:
150 IPM
Vertical table feeds:
(32) 3/16 TO 45 IPM
Feed motor, horsepower:
5
Longitudinal table travel:
42"
Spindle motor, horsepower:
25
Center of spindle to table:
3" MIN, 27" MAX
Subcategory:
Mill

Description

SERIAL .............................. 9J44H5P-2
MODEL ............................... 425-20 VERCIPOWER
AREA OF TABLE ....................... 86-1/2" X 20"
SPINDLE SPEEDS ...................... (24) 14 TO 1400 RPM
LONGITUDINAL & CROSS TABLE FEEDS .... (32) 3/8 TO 90 IPM
VERTICAL TABLE FEEDS ................ (32) 3/16 TO 45 IPM
LONGITUDINAL TABLE TRAVEL ........... 42"
CROSS TABLE TRAVEL .................. 18"
VERTICAL TRAVEL OF SPINDLE CARRIER .. 24"
CENTER OF SPINDLE TO TABLE .......... 3" MIN, 27" MAX
SPINDLE TAPER ....................... #50 NS
TABLE RAPID TRAVERSE ................ 150 IPM
COOLANT ............................. YES
FEED MOTOR, HORSEPOWER .............. 5
SPINDLE MOTOR, HORSEPOWER ........... 25
