Top Seller
Tannewitz 36 " VERTICAL BANDSAW
Location:
Holland, OH
Manufacturer:
Tannewitz
Model:
36
Motor:
10 HORSEPOWER

Specifications

Condition:
used
Stock number:
2131
Motor:
10 HORSEPOWER
Serial:
15147
Model 2:
3600MH
Table feed:
0 TO 14 FPM
Table tilts:
10 DEGREES LEFT, 45 DEGREES RIGHT
Blade speeds:
45 TO 9000 FPM (VARIABLE)
Blade welder:
YES
Area of table:
32" X 34"
Width of blade:
1/8" TO 1-1/4"
Depth of throat:
36"
Hydraulic motor:
1/2 HORSEPOWER
Length of blade:
14 10" 2-WHEEL, 17 2" 3-WHEEL
Stroke of table:
13"
Maximum under guide:
13"
Hydraulic table travel:
YES
Depth of auxilary throat:
24"
Subcategory:
Saw- vertical band

Description

SERIAL ....................... 15147
MODEL ........................ 3600MH
DEPTH OF THROAT .............. 36"
DEPTH OF AUXILARY THROAT ..... 24"
MAXIMUM UNDER GUIDE .......... 13"
AREA OF TABLE ................ 32" X 34"
HYDRAULIC TABLE TRAVEL ....... YES
STROKE OF TABLE .............. 13"
TABLE FEED ................... 0 TO 14 FPM
TABLE TILTS .................. 10 DEGREES LEFT, 45 DEGREES RIGHT
BLADE SPEEDS ................. 45 TO 9000 FPM (VARIABLE)
WIDTH OF BLADE ............... 1/8" TO 1-1/4"
LENGTH OF BLADE .............. 14 10" 2-WHEEL, 17 2" 3-WHEEL
BLADE WELDER ................. YES
FOOT CONTROL FOR TABLE FEED .. YES
MOTOR ........................ 10 HORSEPOWER
HYDRAULIC MOTOR .............. 1/2 HORSEPOWER
